Product Details
| Manufacturer | |||
|---|---|---|---|
| Model | YCMG-S20 | YCMG-S25 | YCMG-S35 |
| Load capacity(kg) | 2000 | 2500 | 3000 |
| Outside fork width(mm) | 570 | 570 | 700 |
| Inside fork width(mm) | 250 | 250 | 400 |
| Fork length(mm) | 1150 | 1150 | 1150 |
| Forkwidth(mm) | 150 | 150 | 150 |
| Lowered height(mm) | 85 | 85 | 85 |
| Lifting height | 195 | 195 | 195 |
| Wheel type | Polyurethane | Polyurethane | Polyurethane |
| Steel wheels(mm) | 180 | 180 | 180 |
| Load wheels(mm) | 150 | 150 | 150 |
| Ground clearance(mm) | 30 | 30 | 30 |
| Turning radius | 1250 | 1250 | 1300 |
| Power type | Manual | Manual | Manual |
| Operation | Walkie | Walkie | Walkie |
| Overall length(mm) | 1150 | 1150 | 1150 |
| Overall height(mm) | 1200 | 1200 | 1200 |
| Weight(kg) | 91.5 | 95.5 | 100 |
| HS Code | 8427100 | 8427100 | 8427100 |
| Packing | 6pcs/wooden pallet | 6pcs/wooden pallet | 6pcs/wooden pallet |
| Warrenty | 12months | 12months | 12months |
| Customize | Accept | Accept | Accept |
| Accuracy | 0.1kg | 0.1kg | 0.1kg |
