Product Details
| 5Ton 2WD/4WD Rough Terrain Forklift | |||
|---|---|---|---|
| 1.1 | Model | CPCY50 | |
| 1.2 | Power Type | Diesel | |
| 1.3 | Rated Capacity | kg | 5000 |
| 1.4 | Load Center Distance | mm | 550 |
| 1.5 | Drive Type | All-time 2WD/4WD | |
| Dimension Parameter | |||
| 2.1 | Standard Lift Height | mm | 3000 |
| 2.2 | Fork Size(L*W*H) | mm | 1370×150×55 |
| 2.3 | Mast inclination angle (F/R) | Deg | 6\12 |
| 2.4 | Overall Length (without fork) | 3450 | |
| 2.5 | Overall Width | mm | 1860 |
| 2.6 | Mast Height | mm | 2557 |
| 2.8 | Head Guard Height | mm | 2450 |
| 2.10 | Ground Clearance | mm | 320 |
| 2.11 | Minimum Turning Radius | mm | 3890 |
| 2.12 | Wheelbase | mm | 1950 |
| 2.13 | Front wheel tread | mm | 1480 |
| 2.14 | Rear wheel tread | mm | 1380 |
| 2.15 | Self Weight | kg | 7000/7200 |
| 2.16 | Overall Height(2 Stage 3m Mast) | mm | 2557 |
| 2.17 | Overall Height(2 Stage 4m Mast) | mm | 3107 |
| 2.18 | Overall Height(2 Stage 5m Mast) | mm | 3607 |
| 2.19 | Overall Height(3 Stage 5m Mast) | mm | 2707 |
| 2.20 | Overall Height(3 Stage 6m Mast) | mm | 3142 |
| Performance Parameter | |||
| 3.1 | MaximumTravel Speed | Km\h | 36 |
| 3.2 | Lifting Speed | mm\s | 430 |
| 3..3 | Lowering Speed | mm\s | 460 |
| 3.4 | Maximum Gradeability | ％ | 40 |
| Tire | |||
| 4.1 | Front Tyre | 16/70-20 | |
| 4.2 | Rear Tyre | 10-16.5 | |
| Engine and Gearbox | |||
| 5.1 | Battery | V\Ah | 24\60 |
| 5.2 | Engine Manufacturer | Cumminsi | |
| 5.3 | Engine Model | QSF3.8-C100 | |
| 5.4 | Rated Power/RPM | kw | 97/2200 |
| 5.5 | Fuel Tank Capacity | L | 110 |
| 5.6 | Gearbox Model | 280 | |
| 5.7 | Transmission Type | Hydrodynamic | |
