Product Details
| 4-WHEEL ELECTRIC FORKLIFT3.O-3.5TON | ||||
|---|---|---|---|---|
| 1.01 | Model | P30H | P35H | |
| 1.02 | Power Type | Electric | Electric | |
| 1.03 | Rated Capacity | kg | 3000 | 3500 |
| 1.04 | Load Centre | mm | 500 | 500 |
| 1.05 | service weight | kg | 4520 | 4800 |
| 2.01 | Tyre Type(Front/Rear) | Pneumatic | Pneumatic | |
| 2.02 | Wheel number X=drive wheel(front/Rear) | 2X/2 | 2X/2 | |
| 2.03 | Tyre Size (Front) | 28x9-15-14PR | 28x9-15-14PR | |
| 2.04 | Tyre Size (Rear) | 6.50-10-10PR | 6.50-10-10PR | |
| 2.05 | Front Tread | mm | 1000 | 1000 |
| 2.06 | Rear Tread | mm | 970 | 970 |
| 2.07 | Wheelbase | mm | 1700 | 1700 |
| 3.01 | Fork Size (LxWxT) | mm | 1070x125x45 | 1070x125x50 |
| 3.02 | Mast Tilt Angle (F/R) | deg | 6/12 | 6/12 |
| 3.03 | Lift Height | mm | 3000 | 3000 |
| 3.04 | Mast Lowered Height | mm | 2115 | 2150 |
| 3.05 | Mast Extended Height | mm | 4180 | 4180 |
| 3.06 | Length to Face of Fork | mm | 2741 | 2796 |
| 3.07 | Overall Width | mm | 1230 | 1230 |
| 3.08 | Distance From Roof to Seat | mm | 1020 | 1020 |
| 3.09 | Front Overhang | mm | 481 | 506 |
| 3.10 | Rear Overhang | mm | 575 | 610 |
| 3.11 | Turning Radius (outside) | mm | 2460 | 2495 |
| 3.12 | Ground Clearance | mm | 140 | 140 |
| 4.01 | Max.Travel Speed (Full load/No load) | km/h | 20/20 | 20/20 |
| 4.02 | Lifting Speed (Full load/No load) | mm/s | 520/530 | 430/440 |
| 4.03 | Lowering Speed (Full load/No load) | mm/s | ≤600/≥300 | ≤600/≥300 |
| 4.04 | Max.Gradeability (Full load) | % | 20 | 20 |
| 5.01 | Battery(Type) | Li-Ion | Li-Ion | |
| 5.02 | Battery(Voltage/Capacity) | V/Ah | 309.12/96 | 309.12/96 |
| 5.03 | Traction Motor Power,S2-60min | Kw | 30 | 30 |
| 5.04 | Lifting Motor Power,S3-15% | Kw | 30 | 30 |
| 5.05 | Controller | Full AC | Full AC | |
| 5.06 | Operating Pressure | Mpa | 18 | 18 |
| 5.07 | Hydraulic Oil Tank Capacity | L | 49 | 49 |
