Product Details
| 3T 2WD Rough Terrain Forklift | |||
|---|---|---|---|
| Model | YCMG302WD | ||
| Power Type | Diesel | ||
| Rated Capacity | kg | 3000 | |
| Load Centre | mm | 600 | |
| Service weight | kg | 4800 | |
| Tyre Type (Front/Rear) | Pneumatic Tire | ||
| Wheel number X = drive wheel (Front/Rear) | 2X/2 | ||
| Tyre Size (Front) | 14-17.5-14PR | ||
| Tyre Size (Rear) | 27X10-12-12PR | ||
| Front Tread | W1 | mm | 1250 |
| Rear Tread | W2 | mm | 1205 |
| Wheelbase | L4 | mm | 1835 |
| Fork Size (LxWxT) | L1 | mm | 1220x125x45 |
| Mast Tilt Angle (F/R) | α/β | deg | August 10 |
| Lift Height | H | mm | 3000 |
| Mast Lowered Height | H1 | mm | 2205 |
| Free Lift Height | H5 | mm | 110 |
| Mast Extended Height | H2 | mm | 4200 |
| Length to Face of Fork | L | mm | 3046 |
| Overall Width | W | mm | 1605 |
| Overhead Guard Height | H3 | mm | 2150 |
| Front Overhang | L2 | mm | 591 |
| Rear Overhang | L3 | mm | 620 |
| Turning Radius (outside) | r | mm | 2750 |
| Ground Clearance (Bottom of mast) | H4 | mm | 230 |
| Min. intersecting aisle | Ra | mm | 2900 |
| Min. right angle stacking aisle width | RASA | mm | 4550 |
| Max. Travel Speed (Full load/No load) | km/h | 19/20 | |
| Lifting Speed (Full load/No load) | mm/s | 430/500 | |
| Lowering Speed (Full load/No load) | mm/s | ≤600 / ≥300 | |
| Max. Gradeability (Full load) | % | 16 | |
| Engine Model | 4D32G31-059 | ||
| Rated output/r.p.m | kw/rpm | 36.8/2500 | |
| Rated torque/r.p.m | Nm/rpm | 186/1600-1800 | |
| No. of Cylinder | 4 | ||
| Bore x Stroke | mm | 98x105 | |
| Displacement | L | 3.167 | |
| Emission Standards | CN III | ||
| Fuel Tank Capacity | L | 60 | |
| Battery (Voltage/Capacity) | V/Ah | 12/80 | |
| Transmission Type | Hydraulic | ||
| Stage FWD/RVS | 1/1Powershifting | ||
| Operating Pressure | Mpa | 18 | |
