Product Details
| PARAMETER | |||
|---|---|---|---|
| Specification | Unit | Seated Model | Stand-up model |
| Max loading | kg | 500 | 400 |
| Center distance | mm | 300 | 300 |
| Max lift Height | mm | 2500 | 2100 |
| Door incline | degree | 6/6(forward and back) | 6/6 |
| Turning radius | mm | 950 | 750 |
| Climb angle | % | 16 | 16 |
| Body length | mm | 1400 | 1100 |
| Overall length | mm | 2050 | 1750 |
| Overall width | mm | 750 | 750 |
| Overall height | mm | 1550 | 1550 |
| Fork length | mm | 650 | 650 |
| Fork thickness | mm | 40 | 40 |
| Min height | mm | 120 | 70 |
| Front wheel | mm | 400*100 Solid | 300*100 |
| Back wheel | mm | 300*100 Solid | 8 inch |
| Battery | V | 48 | 48 |
| Battery capacity | AH | 45 | 32 |
| Net weight | kg | 600 | 500 |
| Keep working | h | 5-6 | 5 |
| Charging time | h | 6 | 6-8 |
| Walking motor | kw | 0.5 | 0.5 |
| Lifting motor | kw | 0.8 | 0.8 |
| Walking speed | Km/h | 5 | 5 |
| Brake type | Drum brake | Disc brake | |
| Turning type | Hydraulic steering | Handle | |
