Product Details
| distinguishing mark | ||||
|---|---|---|---|---|
| 1.1 | Manufacturer | Grue portante avant pour conteneurs | Grue portante avant pour conteneurs | |
| 1.2 | Model designation | ZL450-Atype45t | ||
| 1.3 | Operator type(hand,pedestrian,standing,seated,order-picker) | Car type | Car type | |
| 1.4 | load capacity at load centre distance c1 | Q1(t) | 45 | 45 |
| 1.5 | load capacity at load centre distance c2 | Q2(t) | 31 | 31 |
| 1.6 | load capacity at load centre distance c3 | Q₃ (t) | 15 | |
| 1.7 | Load distance,centre of drive axle to fork | ×(mm) | 835 | 805 |
| 1.8 | Wheelbase | y(mm) | 6000 | 6000 |
| Weight | ||||
| 2.1 | Service weight | kg | 72000 | 71000 |
| Tires,chassis | ||||
| 3.1 | Tyre type (solid rubber,superelastic,pneumatic,polyurethane) | rubber | rubber | |
| 3.2 | Tyre size,front | 1670X515 | 1610X510 | |
| 3.3 | Tyre size,rear | 1670X515 | 1610X510 | |
| 3.4 | Wheels,number front/rear(x=drive wheels) | 4 | 4 | |
| 3.5 | Tread,front | b1o(mm) | 3056 | 3105 |
| 3.6 | Tread,rear | b11(mm) | 2688 | 2688 |
| Dimensions | ||||
| 4.1 | Height,mast lowered | h1(mm) | 4686 | 4660 |
| 4.2 | Lift height | h₃ (mm) | 15100 | 9188 |
| 4.3 | Lift height at load centre c1 | h3.1(mm) | 13000 | 7840 |
| 4.4 | Lift height at load centre c2 | h3.2(mm) | 10450 | 5240 |
| 4.5 | Lift height at load centre c3 | h3.3(mm) | 7840 | |
| 4.6 | Height,mast extended | h4(mm) | 18268 | 12731 |
| 4.7 | Height of overhead guard (cabin) | hs(mm) | 3770 | 3770 |
| 4.8 | Seat height/standing height | h7(mm) | 2787 | 2787 |
| 4.9 | Overall length | l₁ (mm) | 8120 | 8190 |
| 4.10 | Overall width | b1(mm) | 4149 | 4220 |
| 4.11 | Overall width across spreader 20′ | b3.20(mm) | 6058 | 6058 |
| 4.12 | Overall width across spreader 40′ | b3.40(mm) | 12191 | 12191 |
| 4.13 | Ground clearance,center of wheelbase | m2(mm) | 360 | 360 |
