Product Details

G-SERIES DIESEL FORKLIFT 25.0-33.0 TON
General	1	Model				FD250	FD280	FD300	FD330
	2	Power Type				Diesel	Diesel	Diesel	Diesel
	3	Rated Capacity			kg	25000	28000	30000	33000
	4	Load Centre			mm	1200	1200	1200	900
Characteristic&Dimension	5	Lift Height			mm	4000	4000	4000	4000
	6	Fork Size	L×W×T		mm	2440×250x1102440×250x110		2440×250x1102440x250x110
	7	Mast Tilt Angle	F/R		Deg	5°/10°	5°/10°	5°/10°	5°/10°
	8	Front Overhang(Wheel center to fork face)			mm	1240	1240	1240	1240
	9	Ground Clearance(Bottom of mast)			mm	250	250	250	250
	10	Overall Dimension	Length to face of fork(Without fork)		mm	6855	6855	6855	6855
	11		Overall Width		mm	3050	3050	3050	3050
	12		Mast Lowered Height		mm	4000	4000	4000	4000
	13		Mast Extended Height(With backrest)		mm	6000	6000	6000	6000
	14		Overhead Guard Height		mm	3500	3500	3500	3500
	15	Turning Radius(outside)			mm	6500	6500	6500	6500
	16	Min.inserting aisle			mm	8800	8800	8800	8800
Performance	17	Speed	Travel (Empty load)		km/h	25	25	25	25
	18		Lifting(Full load)		mm/s	300	300	300	300
	19	Max.Gradeability			%	20	20	20	20
Chassis	20	Tire	Front			14.00-24	14.00-24	14.00-24	14.00-24
	21		Rear			14.00-24	14.00-24	14.00-24	14.00-24
	22	Wheelbase			mm	4650	4650	4650	4650
	23	Service weight			kg	36600	38600	39600	40500
Power&Transmission	24	Battery	Voltage/Capacity		V/Ah	24/180	24/180	24/180	24/180
	25	Engine	Model		TAD750VE
	26		Manufacturer		VOLVO
	27		Rated output/r.p.m.		kw	181/2300
	28		Rated torque/r.p.m.		N ·m	1050/1500
	29		No.of Cylinder			6
	30		Bore×Stroke		mm	130×108
	31		Displacement		cc	7150
	32		Fuel Tank Capacity		L	420	420	420	420
	33	Transmission	Type			Hydraulic	Hydraulic	Hydraulic	Hydraulic
	34		Stage	FWD/RVS		3/3	3/3	3/3	3/3
	35	Operating Pressure for Attachment			Mpa	19	19	19	19
